RIGOL DP832A
195 W 3-Channel Programmable DC Power Supply · DP800 Series
The DP832A is RIGOL's best-known bench supply in its high-resolution form: three outputs (30 V/3 A, 30 V/3 A and 5 V/3 A, 195 W total) with low-noise linear regulation, 0.1 mV/0.1 mA readback and LAN, RS-232 and digital I/O as standard. It powers most mixed-voltage prototypes from one instrument and measures what they draw.
List price $619
Quote-only: send the form and we confirm your price, any current RIGOL promotion and the lead time.
Ships within the USA only (50 states, DC, Puerto Rico, Guam, USVI, American Samoa, Northern Mariana Islands). Outside the US? Send an international inquiry
CH1RIGOL DP832A at a glance
- Three outputs: 30 V/3 A, 30 V/3 A and 5 V/3 A, 195 W total.
- 0.1 mV / 0.1 mA readback resolution for measuring board current.
- Linear regulation: under 350 µVrms / 2 mVpp ripple and noise.
- Recorder, analyzer, monitor and trigger functions standard on the A model.
- USB, LAN, RS-232 and digital I/O standard; OVP, OCP and OTP protection.
CH2RIGOL DP832A specifications
| Figure | DP832A | Source |
|---|---|---|
| Part number | DP832A | RIGOL |
| Brand | RIGOL | RIGOL |
| Series | DP800 Series | RIGOL price list |
| Display | 3.5-inch TFT | DP800 datasheet |
| Interfaces | USB Host & Device, LAN, RS-232, digital I/O (standard on A models); USB-GPIB optional | DP800 datasheet |
| Total power | 195 W | DP800 datasheet |
| Outputs | 3 (30 V/3 A, 30 V/3 A, 5 V/3 A) | DP800 datasheet |
| Max. voltage | 30 Volts | rigolna.com |
| Max. current | 3 Amps | rigolna.com |
| Output ranges | CH1 30 V/3 A, CH2 30 V/3 A, CH3 5 V/3 A | DP800 datasheet |
| Readback resolution | 0.1 mV / 0.1 mA (display 1 mV / 1 mA) | DP800 datasheet resolution table |
| Ripple and noise | < 350 µVrms / 2 mVpp (multi-output models) | DP800 datasheet |
| Dimensions | 239 × 157 × 418 mm (W×H×D) | DP800 datasheet |
| Weight | 10.5 kg | DP800 datasheet mechanical |
| Country of origin | Malaysia | RIGOL price list |
| Shipping dimensions | 23 × 15 × 12 in | RIGOL price list |
| Shipping weight | 30 lb | RIGOL price list |
RIGOL's own figures, from its data sheets and RIGOL North America's site; RIGOL's data sheet is the full reference. Documents: Datasheet · Specifications · User manual · Quick guide · RIGOL's series page.
CH3In the box, and what it is for
What's in the box
- Spare Fuses
- USB Cable
- Calibration Certificate
- Power Cord
Standard accessories as RIGOL lists them; your quote confirms them.
What it's good for
- Powering 3.3 V/5 V logic plus a ±15 V analog section from one supply (CH1/CH2 can be combined).
- Measuring a prototype's current draw with 0.1 mA readback.
- Automated test and power cycling over LAN with SCPI.
CH4Questions buyers ask
Does it have overvoltage and overcurrent protection?
Yes. Over-voltage (OVP), over-current (OCP) and over-temperature (OTP) protection are standard, set per channel.
What's the difference between the DP832 and DP832A?
The DP832A adds finer readback (0.1 mV/0.1 mA vs 10 mV/10 mA), the recorder/analyzer/monitor/trigger functions, and LAN, RS-232 and digital I/O as standard.
Are the outputs isolated?
CH1 is isolated from CH2 and CH3, so it can be put in series or parallel with either of them. CH2 and CH3 share a common and can't be combined with each other. If your setup needs two floating rails, tell us and we'll suggest a fully isolated DP900 or DP2000 instead.
Is it programmable from a PC?
Yes, over USB or LAN with SCPI commands, or with RIGOL's Ultra Power software.
Does it come with a user manual?
RIGOL's in-box list is the power cord, USB cable, spare fuses and calibration certificate. The user guide and programming guide are free PDFs from RIGOL, linked under Documents on this page.
What do the A models add?
Finer readback resolution, the recorder/analyzer/monitor/trigger functions, and LAN, RS-232 and digital I/O as standard. On the non-A models those are optional.
CH1Request a quote for the DP832A
Options and accessories for the DP832A
Options & upgrades (4)
| Part | Description | List price | Quote |
|---|---|---|---|
| AFK-DP800 | Detect and Analyzer option for DP832, DP811, DP821, DP831 | $108 | |
| DIGITALIO-DP800 | Four channels for trigger in & out option for DP832, DP811, DP821, DP831 | $108 | |
| HIRES-DP800 | 1mV/1mA Resolution Option for DP832, DP811, DP821, DP831 | $108 | |
| INTERFACE-DP800 | RS-232 and LAN interface option for DP832, DP811, DP821, DP831 | $140 |
Accessories (4)
| Part | Description | List price | Quote |
|---|---|---|---|
| 10A-Testing-Cable | 10 A testing cable for DP Series | $25 | |
| SPG-DP800 | Green Safty Plug for DP800 | $59 | |
| RM-2-DP800 | Rack Mount Kit for DP800 series Power Supplies and DL3000 Loads | $122 | |
| RM-1-DP800 | Rack Mount Kit for DP800 series Power Supplies and DL3000 Loads | $137 |
Extended warranty (1)
| Part | Description | List price | Quote |
|---|---|---|---|
| DP832A (R5-1) | DP832A extended warranty, 2 years, option with new product | $61 |
Other models
DP831 · DP832 · DP821 · DP811 · DP831A · DP813 · DP822 · DP811A · DP821A · DP813A · DP822A · compare the DP800 Series
