RIGOL DHO924S
250 MHz 4-Channel 12-bit Mixed Signal Oscilloscope · DHO900 Series
The DHO924S is the most capable DHO900: four 250 MHz analog channels at 12 bits, 16 digital channels with the PLA2216 probe, and a built-in signal source that drives RIGOL's Bode plot analysis. You can sweep a power supply's control loop, generate a test stimulus and watch the result on one compact instrument.
List price $899
Quote-only: send the form and we confirm your price, any current RIGOL promotion and the lead time.
Ships within the USA only (50 states, DC, Puerto Rico, Guam, USVI, American Samoa, Northern Mariana Islands). Outside the US? Send an international inquiry
CH1RIGOL DHO924S at a glance
- 250 MHz on 4 analog channels with 12-bit resolution.
- Built-in signal source: 1 channel, 25 MHz sine, 15 MHz square, 14-bit.
- Bode plot analysis from 10 Hz to 25 MHz using the built-in source.
- 16 digital channels (PLA2216 probe); 50 Mpts memory at 1.25 GSa/s.
- 7-inch touch screen; USB, LAN and HDMI; source output on a rear BNC.
CH2RIGOL DHO924S specifications
| Figure | DHO924S | Source |
|---|---|---|
| Part number | DHO924S | RIGOL |
| Brand | RIGOL | RIGOL |
| Series | DHO900 Series | RIGOL price list |
| Bandwidth | 250 MHz | DHO900 datasheet (DHO900_DataSheet_EN) |
| Analog channels | 4 | DHO900 datasheet (DHO900_DataSheet_EN) |
| Vertical resolution | 12-bit | DHO900 datasheet |
| Max. memory depth | 50 Mpts | DHO900 datasheet |
| Max. real-time sample rate | 1.25 GSa/s | DHO900 datasheet |
| Max. waveform capture rate | 1 Mwfms/s | rigolna.com |
| Digital channels | 16 (PLA2216 probe required) | DHO900 datasheet |
| Built-in generator | 1 channel, 25 MHz sine / 15 MHz square, 156 MSa/s, 14-bit; rear BNC | DHO900 datasheet (DHO900_DataSheet_EN) (AFG, typical) |
| Display | 7-inch 1024×600 capacitive multi-touch | DHO900 datasheet |
| Interfaces | USB Device & Host, LAN (LXI-C, Web Control), HDMI | DHO900 datasheet |
| Dimensions | 265.35 × 161.75 × 77.38 mm (W×H×D) | DHO900 datasheet |
| Weight | 1.78 kg without package | DHO900 datasheet |
| Country of origin | Malaysia | RIGOL price list |
| Shipping dimensions | 13.5 × 9.76 × 5.62 in | RIGOL price list |
| Shipping weight | 6.5 lb | RIGOL price list |
RIGOL's own figures, from its data sheets and RIGOL North America's site; RIGOL's data sheet is the full reference. Documents: RIGOL's series page.
CH3In the box, and what it is for
What's in the box
- Probes - 1 per channel
- Calibration Certificate
- Power Cord
- USB Cable
Standard accessories as RIGOL lists them; your quote confirms them.
What it's good for
- Measuring power-supply loop gain and phase margin with the Bode plot.
- Stimulus-response tests of filters and amplifiers without a separate generator.
- Mixed-signal embedded debug on 4 analog + 16 digital channels.
CH4Questions buyers ask
Can the DHO924S do Bode plots?
Yes. The S models include the signal source and Bode plot, with sweeps from 10 Hz to 25 MHz.
How many channels does the built-in generator have?
One, on a rear-panel BNC: 25 MHz sine, 15 MHz square.
Is the logic analyzer included?
The 16 digital channels are built in, but the PLA2216 logic probe that connects them is sold separately. Add it to the same quote.
What protocols does it decode?
Parallel, RS232/UART, I2C, SPI, CAN and LIN as standard, up to 4 decodes at once.
Does it work with a PC?
Yes: USB device and LAN (LXI-C) for SCPI control, plus a Web Control page you can open in a browser to operate the scope remotely.
What does the S on DHO914S and DHO924S mean?
The S models include RIGOL's built-in signal source (arbitrary waveform generator), which also drives the Bode plot function. Otherwise they match the DHO914 and DHO924.
CH1Request a quote for the DHO924S
Options and accessories for the DHO924S
Probes (18)
| Part | Description | List price | Quote |
|---|---|---|---|
| RP1300H | 100:1 300 MHz TO 2KV PASSIVE PROBE | $243 | |
| PLA2216 | 16 Channel Digital Logic Probe | $399 | |
| RP1025D | High Voltage Differential Probe, DC-25 MHz, 1400 Vpp | $473 | |
| RP1010H | High Voltage Probe with 40MHz bandwidth, 10kV max DC voltage, 1000:1 | $524 | |
| RP1050D | High Voltage Differential Probe, DC-50 MHz, 7000 Vpp | $683 | |
| RP1100D | High Voltage Differential Probe, DC-100 MHz, 7000 Vpp | $788 | |
| PHA0150 | 70 MHz 1500 V Differential Voltage Probe | $799 | |
| RP1001C | Current Probe, DC-300 kHz, 100 Apeak | $867 | |
| PHA1150 | 100 MHz 1500 V Differential Voltage Probe | $999 | |
| RP1018H | High Voltage Probe with 150MHz bandwidth, 18kV max DC voltage, 1000:1 | $1,038 | |
| RP1000P | RP1003C/RP1004C/RP1005C probe power supply | $1,560 | |
| PHA2150 | 200MHz, 1500V High Voltage Differential Probe | $1,590 | |
| RP1003C | Current Probe, DC-50 MHz, 50A peak. Requires RP1000P power supply. | $3,408 | |
| RP1005C | Current Probe, DC-10 MHz, 300A peak. Requires RP1000P power supply. | $4,332 | |
| RP1004C | Current Probe, DC-100 MHz, 50 A peak. Requires RP1000P power supply. | $4,909 | |
| RP1006C | Current Probe, DC-2 MHz, 500A peak. Requires RP1000P power supply. ≤25mArms noise | $5,490 | |
| PIA1050 | 500MHz optical isolation probe, standard with one 50x and one 2000x attenuator. | $9,999 | |
| PIA1100 | 1GHz optical isolation probe, standard with one 50x and one 2000x attenuator. | $15,199 |
Accessories (4)
| Part | Description | List price | Quote |
|---|---|---|---|
| ADP0150BNC | 50 Ohm impedance adapter for oscilloscopes or generators | $19 | |
| CB-BNC-BNC-MM-100 | BNC Cable (length 1 meter) | $20 | |
| BAG-800 | Instrument Carry Case for a DHO800/900, DG800/900 Pro, DM800 | $69 | |
| RM5041 | Ultra-Portable Platform Rack Mount Kit | $179 |
Extended warranty (1)
| Part | Description | List price | Quote |
|---|---|---|---|
| DHO924S (R5-1) | DHO924S extended warranty, 2 years, option with new product | $81 |
